5R20/MAS/927-22/P/E26/WG 6/1FB T20

Specifications Show all

General information

Base	E26  [ Single Contact Medium Screw]
EU RoHS compliant	Yes
Nominal Lifetime (Nom)	15000 h
Switching Cycle	50000
Tier	MasterClass

Light technical

Color Code	922-927  [ CCT of 2200K-2700K]
Beam Angle (Nom)	90 °
Initial lumen (Nom)	450 lm
Color Designation	Warm White (WW)
Correlated Color Temperature (Nom)	2200 K	2700 K
Luminous Efficacy (rated) (Nom)	90.00 lm/W
Color Consistency	<4
Color Rendering Index (Nom)	90
LLMF At End Of Nominal Lifetime (Nom)	70 %

Operating and electrical

Input Frequency	60 Hz
Power (Rated) (Nom)	5 W
Lamp Current (Nom)	65 mA
Wattage Equivalent	50 W
Starting Time (Nom)	0.5 s
Warm Up Time to 60% Light (Nom)	0.5 s
Power Factor (Nom)	0.7
Voltage (Nom)	120 V

Temperature

T-Case Maximum (Nom)

167 °F

Controls and dimming

Dimmable

Yes

Mechanical and housing

Bulb Finish	Frosted
Bulb Material	Plastic
Bulb Shape	R20  [ R 63mm]

Approval and application

Energy Consumption kWh/1000 h	- kWh
Energy Certifications	Energy Star

Product data

Order product name	5R20/MAS/927-22/P/E26/WG 6/1FB T20
EAN/UPC - Product	046677456979
Order code	456979
Numerator - Quantity Per Pack	1
Numerator - Packs per outer box	6
Material Nr. (12NC)	929002008904
Net Weight (Piece)	0.077 lb
