    • Attractive, dimmable, and afforadlble LED BR40 lamp solution

      13.3BR40/PER/927/P/E26/DIM 6/1CT T20
      LED
      13.3BR40/PER/927/P/E26/DIM 6/1CT T20
      LED BR40

      13.3BR40/PER/927/P/E26/DIM 6/1CT T20

      Downloads

      Spec Sheet
      Size:716.1 kB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Warm-up time to 60% light
    0.5 s
    Lamp Current (Nom)
    135 mA
    Voltage (Nom)
    120 V
    Power Factor (Fraction)
    0.7
    Wattage Equivalent
    86 W
    Starting Time (Nom)
    0.5 s
    Line Frequency
    60 Hz
    Power Consumption
    13.3 W
    Input Frequency
    60 Hz
    Approval and Application
    EU RoHS compliant
    Yes
    Product Data
    Full product name
    13.3BR40/PER/927/P/E26/DIM 6/1CT T20
    EAN/UPC - Case
    50046677577853
    Order product name
    13.3BR40/PER/927/P/E26/DIM 6/1CT T20
    Order code
    577858
    Numerator - Packs per outer box
    6
    Material number (12NC)
    929003477204
    Numerator - Quantity Per Pack
    1
    Controls and Dimming
    Dimmable
    Only with specific dimmers
    General Information
    Cap-Base
    E26  [Single Contact Medium Screw]
    Switching Cycle
    50,000
    Lighting Technology
    LED
    Nominal lifetime
    15,000 hour(s)
    Mechanical and Housing
    Bulb Shape
    BR40
    Bulb Finish
    Frosted
    Temperature
    T-Case Maximum (Nom)
    194 °F
    Light Technical
    Luminous Flux
    1,204 lumen
    Luminous Efficacy (rated) (Nom)
    90.00 lm/W
    Color rendering index (CRI)
    90
    Correlated Color Temperature (Nom)
    2700 K
    Beam Angle (Nom)
    110 degree(s)
    Color Designation
    Warm White (WW)
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Color Consistency
    <4
    Color Code
    927  [CCT of 2700K]

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Single Contact Medium Screw BR40 Frosted
    Single Contact Medium Screw BR40 Frosted
    E26
    E26
    Performance Diagrams
    Lumen Maintenance Diagram - 13.3BR40/PER/927/P/E26/DIM 6/1CT T20
    Lumen Maintenance Diagram - 13.3BR40/PER/927/P/E26/DIM 6/1CT T20
    Life Expectancy Diagram - 13.3BR40/PER/927/P/E26/DIM 6/1CT T20
    Life Expectancy Diagram - 13.3BR40/PER/927/P/E26/DIM 6/1CT T20
    Photometrics
    General uniform lighting
    General uniform lighting
    Spectral Power Distribution Colour - 13.3BR40/PER/927/P/E26/DIM 6/1CT T20
    Spectral Power Distribution Colour - 13.3BR40/PER/927/P/E26/DIM 6/1CT T20
    Light Distribution Diagram - 13.3BR40/PER/927/P/E26/DIM 6/1CT T20
    Light Distribution Diagram - 13.3BR40/PER/927/P/E26/DIM 6/1CT T20
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES IES File - 13.3BR40/PER/927/P/E26/DIM 6/1CT T20 IES 7.0 kB
