115CC/LED/850/LS EX39 G2 BB 277-480V 3/1

Specifications Show all

General information

Base	EX39  [ Exclusionary Mogul Screw]
EU RoHS compliant	Yes
Nominal Lifetime (Nom)	50000 h
Switching Cycle	50000
Tier	MASTER

Light technical

Color Code	850  [ CCT of 5000K]
Initial lumen (Nom)	18000 lm
Color Designation	Daylight
Correlated Color Temperature (Nom)	5000 K
Luminous Efficacy (rated) (Nom)	156 lm/W
Color Consistency	ANSI 5000K quadrangle
Color Rendering Index (Nom)	80
LLMF At End Of Nominal Lifetime (Nom)	70 %

Operating and electrical

Input Frequency	50 to 60 Hz
Power (Rated) (Nom)	115 W
Lamp Current (Nom)	455 mA
Wattage Equivalent	320(250-320) W
Starting Time (Nom)	1.5 s
Warm Up Time to 60% Light (Nom)	1.5 s
UL Type	HIB_UL Type B (UL classified+RU)
Power Factor (Nom)	0.9
Voltage (Nom)	277-480 V

Temperature

T-Ambient (Max)	131 °F
T-Ambient (Min)	-4 °F
T-Case Maximum (Nom)	91 °F

Controls and dimming

Dimmable

Only with specific dimmers

Mechanical and housing

Bulb Finish	Clear
Bulb Material	Plastic
Bulb Shape	Corncob

Product data

Order product name	115CC/LED/850/LS EX39 G2 BB 277-480V 3/1
EAN/UPC - Product	046677579012
Order code	579011
Numerator - Quantity Per Pack	1
Numerator - Packs per outer box	3
Material Nr. (12NC)	929003507104
Net Weight (Piece)	2.028 lb
