18CC/LED/830/ND E26 G2 BB 6/1

Specifications Show all

Operating and Electrical

Warm-up time to 60% light	1 s
Lamp Current (Nom)	200 mA
Voltage (Nom)	100-277 V
Power Factor (Fraction)	0.9
Starting Time (Nom)	1 s
Line Frequency	50 to 60 Hz
Power Consumption	18 W
Input Frequency	50 to 60 Hz

Approval and Application

Energy Consumption kWh/1000 h	18 kWh
EU RoHS compliant	Yes

Product Data

Full product name	18CC/LED/830/ND E26 G2 BB 6/1
Order code	559633
EAN/UPC - Case	50046677559637
Order product name	18CC/LED/830/ND E26 G2 BB 6/1
Numerator - Packs per outer box	6
Material number (12NC)	929002395204
Numerator - Quantity Per Pack	1

Controls and Dimming

Dimmable

No

General Information

Cap-Base	E26  [Single Contact Medium Screw]
Switching Cycle	50,000
Lighting Technology	LED
Nominal lifetime	50,000 hour(s)

Mechanical and Housing

Bulb Shape	Corncob
Bulb Finish	Clear
Bulb Material	Plastic

Temperature

T-Case Maximum (Nom)	140 °F
Ambient temperature range	-20 °C to 45 °C

Light Technical

Luminous Flux	2,300 lumen
Color rendering index (CRI)	80
Luminous Efficacy (rated) (Nom)	127.00 lm/W
Correlated Color Temperature (Nom)	3000 K
Color Designation	White (WH)
LLMF At End Of Nominal Lifetime (Nom)	70 %
Color Consistency	ANSI 3000K quadrangle
Color Code	830  [CCT of 3000K]
