      2T3/G4/830/ND 12V 6/1PF
      LED
      2T3/G4/830/ND 12V 6/1PF
      LED Specialty Lamps

      2T3/G4/830/ND 12V 6/1PF

      Downloads

      Spec Sheet
      Size:807.5 kB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Lamp Current (Nom)
    240 mA
    Warm-up time to 60% light
    0.5 s
    Voltage (Nom)
    12 V
    Power Factor (Fraction)
    0.5
    Wattage Equivalent
    20 W
    Starting Time (Nom)
    0.5 s
    Line Frequency
    - Hz
    Power Consumption
    2 W
    Input Frequency
    - Hz
    Approval and Application
    Suitable For Accent Lighting
    No
    Energy Certifications
    No
    EU RoHS compliant
    Yes
    Product Data
    Full product name
    2T3/G4/830/ND 12V 6/1PF
    EAN/UPC - Case
    50046677567199
    Order product name
    2T3/G4/830/ND 12V 6/1PF
    Order code
    567198
    Numerator - Packs per outer box
    6
    Material number (12NC)
    929001844223
    Numerator - Quantity Per Pack
    1
    Controls and Dimming
    Dimmable
    No
    General Information
    Cap-Base
    G4  [G4]
    Switching Cycle
    50,000
    Lighting Technology
    LED
    Nominal lifetime
    15,000 hour(s)
    Mechanical and Housing
    Bulb Shape
    Capsule
    Temperature
    T-Case Maximum (Nom)
    132.8 °F
    Light Technical
    Luminous Flux
    200 lumen
    Luminous Efficacy (rated) (Nom)
    100.00 lm/W
    Color rendering index (CRI)
    80
    Correlated Color Temperature (Nom)
    3000 K
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Color Designation
    White (WH)
    Color Consistency
    <6
    Color Code
    830  [CCT of 3000K]

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     G4 Capsule Frosted
    G4 Capsule Frosted
    G4
    G4
    Performance Diagrams
    Lumen Maintenance Diagram - 2T3/G4/830/ND 12V 6/1PF
    Lumen Maintenance Diagram - 2T3/G4/830/ND 12V 6/1PF
    Life Expectancy Diagram - 2T3/G4/830/ND 12V 6/1PF
    Life Expectancy Diagram - 2T3/G4/830/ND 12V 6/1PF
    Photometrics
    Spectral Power Distribution Colour - 2T3/G4/830/ND 12V 6/1PF
    Spectral Power Distribution Colour - 2T3/G4/830/ND 12V 6/1PF
    Light Distribution Diagram - 2T3/G4/830/ND 12V 6/1PF
    Light Distribution Diagram - 2T3/G4/830/ND 12V 6/1PF
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES IES File - 2T3/G4/830/ND 12V 6/1PF IES 36.9 kB
