    • Energy saving elegance in a verstile design

      5G25/PER/UD50/CL/G/E26/D 4/2PFT20
      LED
      5G25/PER/UD50/CL/G/E26/D 4/2PFT20
      LED G25

      5G25/PER/UD50/CL/G/E26/D 4/2PFT20

      Downloads

      Spec Sheet
      Size:1.5 MB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Warm-up time to 60% light
    0.4 s
    Lamp Current (Nom)
    55 mA
    Voltage (Nom)
    120 V
    Wattage Equivalent
    60 W
    Line Frequency
    60 Hz
    Power Consumption
    5 W
    Starting Time (Nom)
    0.5 s
    Power Factor (Fraction)
    0.7
    Input Frequency
    60 Hz
    Approval and Application
    Energy Certifications
    Energy Star
    EU RoHS compliant
    Yes
    Product Data
    Full product name
    5G25/PER/UD50/CL/G/E26/D 4/2PFT20
    EAN/UPC - Case
    50046677564914
    Order code
    564914
    Material number (12NC)
    929002991403
    Numerator - Quantity Per Pack
    1
    Order product name
    5G25/PER/UD50/CL/G/E26/D 4/2PFT20
    Numerator - Packs per outer box
    4
    Controls and Dimming
    Dimmable
    Only with specific dimmers
    General Information
    Cap-Base
    E26  [Single Contact Medium Screw]
    Switching Cycle
    20,000
    Rated Lifetime (Hours)
    15,000 hour(s)
    Nominal lifetime
    15,000 hour(s)
    Lighting Technology
    LED
    Mechanical and Housing
    Bulb Shape
    G25
    Bulb Material
    Glass
    Bulb Finish
    Clear
    Temperature
    Ambient temperature range
    -20 °C to 40 °C
    Light Technical
    Luminous Flux
    500 lumen
    Color Code
    950  [CCT of 5000K]
    Color rendering index (CRI)
    95
    Correlated Color Temperature (Nom)
    5000 K
    Luminous Efficacy (rated) (Nom)
    100 lm/W
    Color Designation
    Daylight
    Color Consistency
    <4
    Color Code
    950  [CCT of 5000K]
    Beam Angle (Nom)
    300 degree(s)
    LLMF At End Of Nominal Lifetime (Nom)
    70 %

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Single Contact Medium Screw G25 Clear
    Single Contact Medium Screw G25 Clear
    E26
    E26
    Performance Diagrams
    Lumen Maintenance Diagram - 5G25/PER/UD50/CL/G/E26/D 4/2PFT20
    Lumen Maintenance Diagram - 5G25/PER/UD50/CL/G/E26/D 4/2PFT20
    Life Expectancy Diagram - 5G25/PER/UD50/CL/G/E26/D 4/2PFT20
    Life Expectancy Diagram - 5G25/PER/UD50/CL/G/E26/D 4/2PFT20
    Photometrics
    General uniform lighting
    General uniform lighting
    Spectral Power Distribution Colour
    Spectral Power Distribution Colour
    Light Distribution Diagram - 5G25/PER/UD50/CL/G/E26/D 4/2PFT20
    Light Distribution Diagram - 5G25/PER/UD50/CL/G/E26/D 4/2PFT20
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES IES File - 5G25/PER/UD50/CL/G/E26/D 4/2PFT20 IES 2.7 kB
