    • Energy saving elegance that gives a beautiful sparkle of light

      3.5BA11/PER/UD50/CL/G/E12/D 6/3PF T20
      LED
      3.5BA11/PER/UD50/CL/G/E12/D 6/3PF T20
      LED BA11

      3.5BA11/PER/UD50/CL/G/E12/D 6/3PF T20

      Downloads

      Spec Sheet
      Size:875.8 kB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Warm-up time to 60% light
    0.4 s
    Lamp Current (Nom)
    40 mA
    Voltage (Nom)
    120 V
    Wattage Equivalent
    40 W
    Line Frequency
    60 Hz
    Power Consumption
    3.5 W
    Starting Time (Nom)
    0.5 s
    Power Factor (Fraction)
    0.7
    Input Frequency
    60 Hz
    Approval and Application
    Energy Certifications
    Energy Star
    EU RoHS compliant
    Yes
    Product Data
    Full product name
    3.5BA11/PER/UD50/CL/G/E12/D 6/3PF T20
    EAN/UPC - Case
    50046677564938
    Order code
    564930
    Material number (12NC)
    929002991603
    Numerator - Quantity Per Pack
    1
    Order product name
    3.5BA11/PER/UD50/CL/G/E12/D 6/3PF T20
    Numerator - Packs per outer box
    6
    Controls and Dimming
    Dimmable
    Only with specific dimmers
    Mechanical and Housing
    Bulb Shape
    BA11
    Bulb Material
    Glass
    Bulb Finish
    Clear
    General Information
    Cap-Base
    E12  [Candelabra Screw]
    Switching Cycle
    20,000
    Rated Lifetime (Hours)
    15,000 hour(s)
    Nominal lifetime
    15,000 hour(s)
    Lighting Technology
    LED
    Temperature
    Ambient temperature range
    -20 °C to 40 °C
    Light Technical
    Luminous Flux
    300 lumen
    Color Code
    950  [CCT of 5000K]
    Color rendering index (CRI)
    95
    Correlated Color Temperature (Nom)
    5000 K
    Luminous Efficacy (rated) (Nom)
    85 lm/W
    Color Designation
    Daylight
    Color Consistency
    <4
    Color Code
    950  [CCT of 5000K]
    Beam Angle (Nom)
    300 degree(s)
    LLMF At End Of Nominal Lifetime (Nom)
    70 %

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Candelabra Screw BA11 Clear
    Candelabra Screw BA11 Clear
    E12
    E12
    Performance Diagrams
    Lumen Maintenance Diagram - 3.5BA11/PER/UD50/CL/G/E12/D 6/3PF T20
    Lumen Maintenance Diagram - 3.5BA11/PER/UD50/CL/G/E12/D 6/3PF T20
    Life Expectancy Diagram - 3.5BA11/PER/UD50/CL/G/E12/D 6/3PF T20
    Life Expectancy Diagram - 3.5BA11/PER/UD50/CL/G/E12/D 6/3PF T20
    Photometrics
    General uniform lighting
    General uniform lighting
    Spectral Power Distribution Colour
    Spectral Power Distribution Colour
    Light Distribution Diagram - 3.5BA11/PER/UD50/CL/G/E12/D 6/3PF T20
    Light Distribution Diagram - 3.5BA11/PER/UD50/CL/G/E12/D 6/3PF T20
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES IES File - 3.5BA11/PER/UD50/CL/G/E12/D 6/3PF T20 IES 2.7 kB
