    • Energy saving elegance that gives a beautiful sparkle of light

      5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20
      LED
      5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20
      LED B11

      5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20

      Downloads

      Spec Sheet
      Size:703.8 kB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Warm-up time to 60% light
    0.5 s
    Lamp Current (Nom)
    55 mA
    Voltage (Nom)
    120 V
    Power Factor (Fraction)
    0.7
    Wattage Equivalent
    60 W
    Line Frequency
    60 Hz
    Power Consumption
    5 W
    Input Frequency
    60 Hz
    Starting Time (Nom)
    0.5 s
    Approval and Application
    Energy Certifications
    Energy Star
    EU RoHS compliant
    Yes
    Product Data
    Full product name
    5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20
    EAN/UPC - Case
    50046677575194
    Order product name
    5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20
    Order code
    575191
    Numerator - Packs per outer box
    10
    Material number (12NC)
    929003082504
    Numerator - Quantity Per Pack
    1
    Controls and Dimming
    Dimmable
    Only with specific dimmers
    General Information
    Cap-Base
    E12  [Candelabra Screw]
    Switching Cycle
    20,000
    Lighting Technology
    LED
    Nominal lifetime
    15,000 hour(s)
    Mechanical and Housing
    Bulb Shape
    B11  [B 35mm]
    Bulb Finish
    Frosted
    Bulb Material
    Glass
    Light Technical
    Luminous Flux
    500 lumen
    Luminous Efficacy (rated) (Nom)
    100.00 lm/W
    Color rendering index (CRI)
    95
    Correlated Color Temperature (Nom)
    2700 K
    2200 K
    Beam Angle (Nom)
    300 degree(s)
    Color Designation
    Warm Glow(WG)
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Color Consistency
    <4
    Color Code
    927-922  [CCT of 2700K-2200K]

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Candelabra Screw B 35mm Frosted
    Candelabra Screw B 35mm Frosted
    E12
    E12
    Performance Diagrams
    Lumen Maintenance Diagram - 5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20
    Lumen Maintenance Diagram - 5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20
    Life Expectancy Diagram - 5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20
    Life Expectancy Diagram - 5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20
    Photometrics
    General uniform lighting
    General uniform lighting
    Spectral Power Distribution Colour - 5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20
    Spectral Power Distribution Colour - 5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20
    Light Distribution Diagram - 5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20
    Light Distribution Diagram - 5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES IES File - 5B11/PER/CRI95WG/FR/G/E12/WGD 1CT T20 IES 3.1 kB
