    • Energy saving elegance that gives a beautiful sparkle of light

      3.5B11/VIN/820/E12/Amber/G/SP D 4/2PFT20
      LED
      3.5B11/VIN/820/E12/Amber/G/SP D 4/2PFT20
      LED B11

      3.5B11/VIN/820/E12/Amber/G/SP D 4/2PFT20

      Downloads

      Spec Sheet
      Size:914.1 kB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Warm-up time to 60% light
    0.5 s
    Lamp Current (Nom)
    41 mA
    Voltage (Nom)
    120 V
    Power Factor (Fraction)
    0.7
    Wattage Equivalent
    25 W
    Starting Time (Nom)
    0.5 s
    Line Frequency
    60 Hz
    Power Consumption
    3.5 W
    Input Frequency
    60 Hz
    Approval and Application
    EU RoHS compliant
    Yes
    Product Data
    Full product name
    3.5B11/VIN/820/E12/Amber/G/SP D 4/2PFT20
    EAN/UPC - Case
    50046677565805
    Order code
    565804
    Numerator - Packs per outer box
    4
    Material number (12NC)
    929002988703
    Numerator - Quantity Per Pack
    1
    Order product name
    3.5B11/VIN/820/E12/Amber/G/SP D 4/2PFT20
    Controls and Dimming
    Dimmable
    Only with specific dimmers
    General Information
    Cap-Base
    E12  [Candelabra Screw]
    Switching Cycle
    20,000
    Lighting Technology
    LED
    Nominal lifetime
    15,000 hour(s)
    Mechanical and Housing
    Bulb Shape
    B11
    Bulb Finish
    Amber
    Bulb Material
    Glass
    Temperature
    Ambient temperature range
    -20 °C to 45 °C
    Light Technical
    Luminous Flux
    225 lumen
    Luminous Efficacy (rated) (Nom)
    64 lm/W
    Color rendering index (CRI)
    80
    Correlated Color Temperature (Nom)
    2000 K
    Beam Angle (Nom)
    330 degree(s)
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Color Designation
    Flame
    Color Consistency
    <6
    Color Code
    820  [CCT of 2000K]

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Candelabra Screw B11 Amber
    Candelabra Screw B11 Amber
    E12
    E12
    Performance Diagrams
    Lumen Maintenance Diagram - 3.5B11/VIN/820/E12/Amber/G/SP D 4/2PFT20
    Lumen Maintenance Diagram - 3.5B11/VIN/820/E12/Amber/G/SP D 4/2PFT20
    Life Expectancy Diagram - 3.5B11/VIN/820/E12/Amber/G/SP D 4/2PFT20
    Life Expectancy Diagram - 3.5B11/VIN/820/E12/Amber/G/SP D 4/2PFT20
    Photometrics
    General uniform lighting
    General uniform lighting
    Spectral Power Distribution Colour
    Spectral Power Distribution Colour
    Light Distribution Diagram - 3.5B11/VIN/820/E12/Amber/G/SP D 4/2PFT20
    Light Distribution Diagram - 3.5B11/VIN/820/E12/Amber/G/SP D 4/2PFT20
