    • Energy saving elegance in a familier design

      6.6A15/PER/UD50/CL/G/E26/DIM2PF T20
      LED
      6.6A15/PER/UD50/CL/G/E26/DIM2PF T20
      LED A15

      6.6A15/PER/UD50/CL/G/E26/DIM2PF T20

      Downloads

      Spec Sheet
      Size:989.7 kB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Lamp Current (Nom)
    65 mA
    Warm-up time to 60% light
    0.4 s
    Voltage (Nom)
    120 V
    Wattage Equivalent
    60 W
    Line Frequency
    60 Hz
    Power Consumption
    6.6 W
    Starting Time (Nom)
    0.5 s
    Power Factor (Fraction)
    0.7
    Input Frequency
    60 Hz
    Approval and Application
    EU RoHS compliant
    Yes
    Product Data
    Full product name
    6.6A15/PER/UD50/CL/G/E26/DIM2PF T20
    EAN/UPC - Product
    50046677573404
    EAN/UPC - Case
    50046677573404
    Order code
    573402
    Material number (12NC)
    929003084503
    Numerator - Quantity Per Pack
    1
    Order product name
    6.6A15/PER/UD50/CL/G/E26/DIM2PF T20
    Numerator - Packs per outer box
    6
    Controls and Dimming
    Dimmable
    Only with specific dimmers
    General Information
    Cap-Base
    E26  [Single Contact Medium Screw]
    Switching Cycle
    20,000
    Rated Lifetime (Hours)
    15,000 hour(s)
    Nominal lifetime
    15,000 hour(s)
    Lighting Technology
    LED
    Mechanical and Housing
    Bulb Shape
    A15  [A 15mm]
    Bulb Material
    Glass
    Bulb Finish
    Clear
    Temperature
    Ambient temperature range
    -20 °C to 40 °C
    Light Technical
    Luminous Flux
    750 lumen
    Color Code
    950  [CCT of 5000K]
    Color rendering index (CRI)
    95
    Correlated Color Temperature (Nom)
    5000 K
    Luminous Efficacy (rated) (Nom)
    113 lm/W
    Color Designation
    Daylight
    Color Consistency
    <4
    Color Code
    950  [CCT of 5000K]
    Beam Angle (Nom)
    300 degree(s)
    LLMF At End Of Nominal Lifetime (Nom)
    70 %

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Single Contact Medium Screw A 15mm Clear
    Single Contact Medium Screw A 15mm Clear
    E26
    E26
    Performance Diagrams
    Lumen Maintenance Diagram - 6.6A15/PER/UD50/CL/G/E26/DIM2PF T20
    Lumen Maintenance Diagram - 6.6A15/PER/UD50/CL/G/E26/DIM2PF T20
    Life Expectancy Diagram - 6.6A15/PER/UD50/CL/G/E26/DIM2PF T20
    Life Expectancy Diagram - 6.6A15/PER/UD50/CL/G/E26/DIM2PF T20
    Photometrics
    General uniform lighting
    General uniform lighting
    Spectral Power Distribution Colour
    Spectral Power Distribution Colour
    Light Distribution Diagram - 6.6A15/PER/UD50/CL/G/E26/DIM2PF T20
    Light Distribution Diagram - 6.6A15/PER/UD50/CL/G/E26/DIM2PF T20
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES IES File - 6.6A15/PER/UD50/CL/G/E26/DIM2PF T20 IES 2.7 kB
