3.5BA11/PER/UD50/CL/G/E26/D 6/3PF T20

Specifications Show all

General information

Base	E26  [ Single Contact Medium Screw]
EU RoHS compliant	Yes
Nominal Lifetime (Nom)	15000 h
Switching Cycle	20000

Light technical

Color Code	950  [ CCT of 5000K]
Beam Angle (Nom)	300 °
Initial lumen (Nom)	300 lm
Color Designation	Daylight
Correlated Color Temperature (Nom)	5000 K
Luminous Efficacy (rated) (Nom)	85 lm/W
Color Consistency	<4
Color Rendering Index (Nom)	95
LLMF At End Of Nominal Lifetime (Nom)	70 %

Operating and electrical

Input Frequency	60 Hz
Power (Rated) (Nom)	3.5 W
Lamp Current (Nom)	40 mA
Wattage Equivalent	40 W
Starting Time (Nom)	0.5 s
Warm Up Time to 60% Light (Nom)	0.4 s
Power Factor (Nom)	0.7
Voltage (Nom)	120 V

Temperature

T-Ambient (Max)	104 °F
T-Ambient (Min)	-4 °F

Controls and dimming

Dimmable

Only with specific dimmers

Mechanical and housing

Bulb Finish	Clear
Bulb Material	Glass
Bulb Shape	BA11

Approval and application

Energy Certifications

Energy Star

Product data

Order product name	3.5BA11/PER/UD50/CL/G/E26/D 6/3PF T20
EAN/UPC - Product	50046677564945
Order code	564948
Numerator - Quantity Per Pack	1
Numerator - Packs per outer box	6
Material Nr. (12NC)	929002991903
Net Weight (Piece)	0.044 lb
