    • Create a vintage look while saving money with LED technology

      1S14/VIN/827/CL/G/E26/ND 1CT
      LED
      1S14/VIN/827/CL/G/E26/ND 1CT
      Classic filament LEDbulbs

      1S14/VIN/827/CL/G/E26/ND 1CT

      Order code: 575209

      Downloads

      Spec Sheet
      Size:761.2 kB

      See all downloads

    Specifications Show all

    General Information
    Base
    E26  [ Single Contact Medium Screw]
    EU RoHS compliant
    Yes
    Nominal Lifetime (Nom)
    15000 h
    Switching Cycle
    20000X
    Light Technical
    Color Code
    827  [ CCT of 2700K]
    Initial lumen (Nom)
    60 lm
    Color Designation
    Warm White (WW)
    Correlated Color Temperature (Nom)
    2700 K
    Luminous Efficacy (rated) (Nom)
    60.00 lm/W
    Color Consistency
    <4
    Color Rendering Index (Nom)
    80
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Operating and Electrical
    Input Frequency
    50 to 60 Hz
    Power (Rated) (Nom)
    1 W
    Lamp Current (Nom)
    12 mA
    Wattage Equivalent
    10 W
    Starting Time (Nom)
    0.5 s
    Warm Up Time to 60% Light (Nom)
    0.5 s
    Power Factor (Nom)
    0.5
    Voltage (Nom)
    110-130 V
    Temperature
    T-Case Maximum (Nom)
    26 °C
    Controls and Dimming
    Dimmable
    No
    Mechanical and Housing
    Bulb Finish
    Clear
    Bulb Shape
    S14  [ S14]
    Product Data
    Order product name
    1S14/VIN/827/CL/G/E26/ND 1CT
    EAN/UPC - Product
    046677575205
    Order code
    575209
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    10
    Material Nr. (12NC)
    929003082704
    Net Weight (Piece)
    0.016 kg

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Single Contact Medium Screw S-14 Clear
    Single Contact Medium Screw S-14 Clear
    E26
    E26
    Performance Diagrams
    15K LMP
    15K LMP
    15K LED
    15K LED
    Photometrics
    LEDbulb NAM 1W S14 E26 827 CL-GUL
    LEDbulb NAM 1W S14 E26 827 CL-GUL
    LEDbulb NAM 1W S14 E26 827 CL-POC
    LEDbulb NAM 1W S14 E26 827 CL-POC
    LEDbulb NAM S14 1W E26 827 CL-LDD
    LEDbulb NAM S14 1W E26 827 CL-LDD
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES LEDbulb NAM 1W S14 E26 827 CL-IES IES 2.5 kB
