    • Actinic BL PL-S/PL-L – compact for design freedom

      PL-S 9W/10/2P Lead Free
      PL-S 9W/10/2P Lead Free
      Actinic BL PL-S/PL-L

      PL-S 9W/10/2P Lead Free

      Order code: 157651

      Downloads

      Spec Sheet
      Size:124.0 kB

      See all downloads

    Specifications Show all

    General information
    Base
    G23  [ G23]
    Main Application
    Insect traps
    Life to 50% Failures (Nom)
    1000 h
    Useful Life (Nom)
    2000 h
    Light technical
    Color Code
    210  [ leadfree 360 glass (10)]
    Color Designation
    Ultra Violet A
    Chromaticity Coordinate X (Nom)
    227
    Chromaticity Coordinate Y (Nom)
    212
    UV Depreciation at 2000 h
    20 %
    Operating and electrical
    Power (Rated) (Nom)
    8.6 W
    Lamp Current (Nom)
    0.17 A
    Voltage (Nom)
    60 V
    Mechanical and housing
    Cap-Base Information
    2 Pins (2P)
    Bulb Shape
    2xT12
    UV
    UV-B/UV-A (IEC)
    0.1 %
    UV-A Radiation 100Hr (IEC)
    1.66 W
    Product data
    Order product name
    Actinic BL PL-S 9W/10/2P 1CT/6X10BOX
    EAN/UPC - Product
    8711500951946
    Order code
    157651
    Numerator - Quantity Per Pack
    1
    Local code description
    Actinic BL PL-S 9W/10/2P 1CT/6X10BOX
    Numerator - Packs per outer box
    60
    Material Nr. (12NC)
    927901721008
    Net Weight (Piece)
    0.071 lb

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
    PL-S
    PL-S
    G23
    G23
    Photometrics
    XDPB_XUAPLS_10_110_210-Spectral power distribution B/W
    XDPB_XUAPLS_10_110_210-Spectral power distribution B/W
    XDPO_XUAPLS_10_110_210-Spectral power distribution Colour
    XDPO_XUAPLS_10_110_210-Spectral power distribution Colour
