    • Actinic BL PL-L Secura - compact and HACCP-approved

      PL-L 36W/10/4P Secura 1CT/25
      PL-L 36W/10/4P Secura 1CT/25
      Actinic BL PL-L Secura

      PL-L 36W/10/4P Secura 1CT/25

      Order code: 285049

      Downloads

      Spec Sheet
      Size:340.9 kB

      See all downloads

    Specifications Show all

    General information
    Base
    2G11  [ 2G11]
    Main Application
    Insect traps
    Life to 50% Failures (Nom)
    10000 h
    Light technical
    Color Code
    10
    Chromaticity Coordinate X (Nom)
    228
    Chromaticity Coordinate Y (Nom)
    215
    UV Depreciation at 2000 h
    20 %
    UV Depreciation at 5000 h
    40 %
    Operating and electrical
    Power (Rated) (Nom)
    36 W
    Lamp Current (Nom)
    0.440 A
    Voltage (Nom)
    108 V
    Mechanical and housing
    Cap-Base Information
    4 Pins (4P)
    Bulb Shape
    2xT16
    Approval and application
    Mercury (Hg) Content (Max)
    2.0 mg
    Mercury (Hg) Content (Nom)
    1.8 mg
    UV
    UV-A Radiation 100Hr (IEC)
    7.7 W
    Product data
    Order product name
    PL-L 36W/10/4P SECURA 1CT/25
    EAN/UPC - Product
    8718291194439
    Order code
    285049
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    25
    Material Nr. (12NC)
    927909121001
    Net Weight (Piece)
    0.293 lb
    Installation Diagrams
    Secura 2G11 4P
    Secura 2G11 4P
    2G11
    2G11
    Photometrics
    XDPB_XURPLL_0001-Spectral power distribution B/W
    XDPB_XURPLL_0001-Spectral power distribution B/W
    XDPO_XURPLL_0001-Spectral power distribution Colour
    XDPO_XURPLL_0001-Spectral power distribution Colour
