MSD 250/2 30H 1CT/4

Specifications Show all

General information

Base	GY9.5  [ GY9.5]
Operating Position	Universal  [ Universal]
Main Application	Studio/Disco
Life to 50% Failures (Nom)	3000 h
System Description	na  [ -]

Light technical

Color Code	850  [ CCT of 5000K]
Initial lumen (Min)	16000 lm
Initial lumen (Nom)	18000 lm
Chromaticity Coordinate X (Nom)	289
Chromaticity Coordinate Y (Nom)	305
Correlated Color Temperature (Nom)	8100 K
Luminous Efficacy (rated) (Nom)	72 lm/W
Color Rendering Index (Nom)	70

Operating and electrical

Power (Rated) (Nom)	250 W
Lamp Current (Nom)	3 A
Ignition Supply Voltage (Min)	207 V

Controls and dimming

Dimmable

No

Mechanical and housing

Cap-Base Information

na  [ -]

Luminaire design requirements

Bulb Temperature (Max)	932 °F
Pinch Temperature (Max)	662 °F
Pinch Temperature (Max)-DUP(do not use)	662 °F

Product data

Order product name	MSD 250/2 30H 1CT/4
EAN/UPC - Product	8718291228066
Order code	287037
Numerator - Quantity Per Pack	1
Numerator - Packs per outer box	4
Material Nr. (12NC)	928099005115
Net Weight (Piece)	0.066 lb
