      C400S51/ALTO 12PK
      C400S51/ALTO 12PK

      C400S51/ALTO 12PK

      Order code: 467373

      Downloads

      Leaflet
      Size:449.7 kB

      See all downloads

    Specifications Show all

    General Information
    Base
    E39  [ Single Contact Mogul Screw]
    Operating Position
    Universal  [ Universal]
    Main Application
    General and Street Lighting
    ANSI Code HID
    S51
    Features
    ALTO® (ALTO)
    Light Technical
    Luminous Flux (Rated) (Min)
    45000 lm
    Luminous Flux (Rated) (Nom)
    50000 lm
    Photosynthetic Photon Flux (PPF)
    595 µmol/s
    Design Mean Lumens
    45000 lm
    Chromaticity Coordinate X (Nom)
    515
    Chromaticity Coordinate Y (Nom)
    420
    Correlated Color Temperature (Nom)
    2100 K
    Luminous Efficacy (Rated) (Min)
    112.5 lm/W
    Luminous Efficacy (rated) (Nom)
    125 lm/W
    Color Rendering Index (Nom)
    20
    Operating and Electrical
    Lamp Current (Nom)
    4.6 A
    Ignition Supply Voltage (Max)
    198 V
    Re-Ignition Time (Min) (Max)
    1 min
    Ignition Time (Max)
    5 s
    Voltage (Max)
    115 V
    Voltage (Min)
    84 V
    Voltage (Nom)
    100 V
    Mechanical and Housing
    Bulb Finish
    Clear
    Cap-Base Information
    Brass  [ Brass Cap]
    Bulb Material
    Hard Glass
    Approval and Application
    Picogram Per Lumen Hour
    26.4 pg/lm.h
    Mercury (Hg) Content (Max)
    23.5 mg
    UV
    Pet (Niosh) (Nom)
    353 h/500lx
    Damage Factor D/fc (Nom)
    0.03
    Luminaire Design Requirements
    Bulb Temperature (Max)
    400 °C
    Cap-Base Temperature (Max)
    210 °C
    Product Data
    Order product name
    SON 400W E39 ED58 CL SL/12
    EAN/UPC - Product
    046677467371
    Order code
    467373
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    12
    Material Nr. (12NC)
    928601139391
    Net Weight (Piece)
    165.000 g
    Installation Diagrams
    E39, ED-18
    E39, ED-18
