    • Switch Start Metal Halide Standard

      MH1500/U 6PK
      MH1500/U 6PK
      Switch Start Metal Halide Standard

      MH1500/U 6PK

      Order code: 131623

      Downloads

      Spec Sheet
      Size:357.4 kB

      See all downloads

    Specifications Show all

    General information
    Base
    E39  [ Single Contact Mogul Screw]
    Operating Position
    Base Up +/- 15 D  [ Base Up +/- 15 D]
    Main Application
    General Lighting (G)
    Life to 50% Failures (Nom)
    6000 h
    ANSI Code HID
    M48/E
    Footnotes HID 1
    Electrically insulated support for bulb may be required, especially in horizontal and nearly horizontal operating positions. (359)
    Footnotes HID 2
    Performance may not be satisfactory unless operated within specified operating positions. (374)
    Footnotes HID 3
    If specified operating position is base up or base down to horizontal, this permits 15 degrees beyond the horizontal. (375)
    Footnotes HID 4
    Requires a ballast specified or approved for Philips metal halide lamps, or one that is designed to operate all popular brands of metal halide lamps. 1000W types will operate from H36 conventional lag type ballast for Mercury Vapor lamps at ambient temperatures of 50 degrees F or higher. 1000W types must not be operated at 1500W. (377)
    Light technical
    Color Code
    640  [ CCT of 4000K]
    Luminous Flux (Rated) (Nom)
    170000 lm
    Color Designation
    White (WH)
    Lumen Maintenance - 40% Life
    65 %
    Design Mean Lumens
    136000 lm
    Chromaticity Coordinate X (Nom)
    0.385
    Chromaticity Coordinate Y (Nom)
    0.390
    Correlated Color Temperature (Nom)
    4000 K
    Luminous Efficacy (rated) (Nom)
    113 lm/W
    Color Rendering Index (Nom)
    65
    Operating and electrical
    Lamp Current (Nom)
    6.2 A
    Ignition Supply Voltage (Min)
    370 V
    Re-Ignition Time (Min) (Max)
    15 min
    Ignition Time (Max)
    120 s
    Voltage (Max)
    283 V
    Voltage (Min)
    253 V
    Voltage (Nom)
    268 V
    Mechanical and housing
    Bulb Finish
    Clear
    Cap-Base Information
    Nic/Brass
    Bulb Material
    Hard Glass
    Bulb Shape
    BT56  [ BT56]
    Approval and application
    Energy Saving Product
    Not Applicable
    Mercury (Hg) Content (Nom)
    228.0 mg
    UV
    Pet (Niosh) (Nom)
    37.5 h/500lx
    Damage Factor D/fc (Nom)
    0.60
    Luminaire design requirements
    Bulb Temperature (Max)
    806 °F
    Cap-Base Temperature (Max)
    482 °F
    Cap-Base Temperature (Max)-DUP(do not use)
    482 °F
    Product data
    Order product name
    MH1500/U 6PK
    EAN/UPC - Product
    046677131623
    Order code
    131623
    Numerator - Quantity Per Pack
    1
    Local code description
    LAMPADA HALETO METALICO MH1500/U 6PK
    Numerator - Packs per outer box
    6
    Material Nr. (12NC)
    928601179401
    Net Weight (Piece)
    0.882 lb
    Installation Diagrams
    E39/E40/41, BT-56
    E39/E40/41, BT-56
    E39
    E39
    OpPos_h15.eps-Operating position
    OpPos_h15.eps-Operating position
