    • Switch Start Metal Halide Protected

      MP1000/BU 6PK
      MP1000/BU 6PK

      MP1000/BU 6PK

      Order code: 281188

      Downloads

      Leaflet
      Size:373.6 kB

      See all downloads

    Specifications Show all

    General Information
    Base
    EX39  [ Exclusionary Mogul Screw]
    Operating Position
    Base Up +/- 15 D  [ Base Up +/- 15 D]
    Main Application
    General Lighting (G)
    Life to 50% Failures (Nom)
    12000 h
    ANSI Code HID
    M47/O
    Light Technical
    Color Code
    635  [ CCT of 3500K]
    Luminous Flux (Rated) (Nom)
    107000 lm
    Color Designation
    White (WH)
    Design Mean Lumens
    69550 lm
    Chromaticity Coordinate X (Nom)
    405
    Chromaticity Coordinate Y (Nom)
    390
    Correlated Color Temperature (Max)
    - K
    Correlated Color Temperature (Min)
    - K
    Correlated Color Temperature (Nom)
    3500 K
    Luminous Efficacy (rated) (Nom)
    107 lm/W
    Color Rendering Index (Nom)
    65
    Operating and Electrical
    Lamp Current (Nom)
    4.1 A
    Ignition Supply Voltage (Min)
    440 V
    Re-Ignition Time (Min) (Max)
    15 min
    Ignition Time (Max)
    120 s
    Voltage (Nom)
    263 V
    Mechanical and Housing
    Bulb Finish
    Clear (CL)
    Cap-Base Information
    Nic/Brass
    Bulb Material
    Hard Glass
    Approval and Application
    Picogram Per Lumen Hour
    173.7 pg/lm.h
    Mercury (Hg) Content (Nom)
    150 mg
    UV
    Pet (Niosh) (Nom)
    59.9 h/500lx
    Damage Factor D/fc (Nom)
    0.70
    Luminaire Design Requirements
    Bulb Temperature (Max)
    430 °C
    Cap-Base Temperature (Max)
    250 °C
    Product Data
    Order product name
    MP1000/BU 6PK
    EAN/UPC - Product
    046677281182
    Order code
    281188
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    6
    Material Nr. (12NC)
    928601179601
    Net Weight (Piece)
    0.001 kg

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
    EX39, BT-56
    EX39, BT-56
    EX39
    EX39
