MP400/BU/PS 6PK

Specifications Show all

General information

Base	EX39  [ Exclusionary Mogul Screw]
Operating Position	Base Up +/- 15 D  [ Base Up +/- 15 D]
Main Application	General Lighting (G)
Life to 50% Failures (Nom)	20000 h
ANSI Code HID	M155/M128/M135/O
System Description	Pulse Start

Light technical

Color Code	635  [ CCT of 3500K]
Luminous Flux (Rated) (Min)	38000 lm
Luminous Flux (Rated) (Nom)	40000 lm
Color Designation	White (WH)
Design Mean Lumens	28000 lm
Chromaticity Coordinate X (Nom)	405
Chromaticity Coordinate Y (Nom)	398
Correlated Color Temperature (Nom)	3800 K
Luminous Efficacy (Rated) (Min)	95 lm/W
Luminous Efficacy (rated) (Nom)	100 lm/W
Color Rendering Index (Nom)	65

Operating and electrical

Lamp Current (Nom)	3.25 A
Ignition Supply Voltage (Min)	350 V
Re-Ignition Time (Min) (Max)	8 min
Ignition Time (Max)	120 s
Voltage (Max)	150 V
Voltage (Min)	120 V
Voltage (Nom)	135 V

Mechanical and housing

Bulb Finish	Clear
Cap-Base Information	Nic/Brass
Bulb Material	Hard Glass
Bulb Shape	ED37  [ ED37]

Approval and application

Mercury (Hg) Content (Nom)

50 mg

Luminaire design requirements

Bulb Temperature (Max)	752 °F
Cap-Base Temperature (Max)	410 °F
Cap-Base Temperature (Max)-DUP(do not use)	410 °F

Product data

Order product name	MP400/BU/PS 6PK
EAN/UPC - Product	046677133344
Order code	133348
Numerator - Quantity Per Pack	1
Numerator - Packs per outer box	6
Material Nr. (12NC)	928601158102
Net Weight (Piece)	0.002 lb
