MHC100/U/MP/4K ELITE

Specifications Show all

Operating and Electrical

Lamp Current (Nom)	1.1 A
Voltage (Nom)	103 V
Voltage (Nom)	103 V

Approval and Application

Mercury (Hg) Content (Max)

10.3 mg

Product Data

Full product name	MHC100/U/MP/4K ELITE
EAN/UPC - Case	50046677429930
Order product name	MHC100/U/MP/4K ELITE
Order code	429936
Numerator - Packs per outer box	12
Material number (12NC)	928601178101
Numerator - Quantity Per Pack	1

General Information

Cap-Base	E26  [Single Contact Medium Screw]
Operating Position	UNIVERSAL  [Any or Universal (U)]
Features	ELITE

Mechanical and Housing

Bulb Shape	ED17P  [ED-17P Protected]
Bulb Finish	Clear
Bulb Material	Hard Glass

Light Technical

Chromaticity Coordinate Y (Nom)	0.371
Chromaticity Coordinate X (Nom)	0.382
Luminous Efficacy (Rated) (Min)	91 lm/W
Luminous Efficacy (rated) (Nom)	94 lm/W
Color rendering index (CRI)	90
Correlated Color Temperature (Nom)	4000 K
Color Designation	Cool White (CW)
Color Code	940  [CCT of 4000K]
