      PL-T 42W/835/XEW/A/4P/33W 1CT/5X10 ALTO
      PL-T 42W/835/XEW/A/4P/33W 1CT/5X10 ALTO
      PL-T Triple 4-Pin Base Energy Advantage

      PL-T 42W/835/XEW/A/4P/33W 1CT/5X10 ALTO

      Order code: 220285

      Downloads

      Spec Sheet
      Size:361.0 kB

      See all downloads

    Specifications Show all

    General information
    Base
    GX24Q-4  [ GX24q-4]
    Life to 50% Failures Preheat (Nom)
    16000 h
    Features
    ALTO® (ALTO)
    Light technical
    Color Code
    835  [ CCT of 3500K]
    Initial lumen (Nom)
    2300 lm
    Color Designation
    White (WH)
    Lumen Maintenance 2000 h (Nom)
    92 %
    Lumen Maintenance 5000 h (Nom)
    87 %
    Correlated Color Temperature (Nom)
    3500 K
    Luminous Efficacy (rated) (Nom)
    67 lm/W
    Color Rendering Index (Nom)
    82
    Operating and electrical
    Power (Rated) (Nom)
    34.5 W
    Lamp Current (Nom)
    0.320 A
    Controls and dimming
    Dimmable
    Yes
    Mechanical and housing
    Cap-Base Information
    4P
    Approval and application
    Mercury (Hg) Content (Nom)
    1.4 mg
    Product data
    Order product name
    PL-T 42W/835/XEW/A/4P/33W 1CT/5X10 ALTO
    EAN/UPC - Product
    046677220280
    Order code
    220285
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    10
    Material Nr. (12NC)
    927908183520
    Net Weight (Piece)
    0.183 lb
    Installation Diagrams
    GX24q-4, 4P
    GX24q-4, 4P
    GX24q-4
    GX24q-4
    Photometrics
    LDPB_PLT4PXEW_835-Spectral power distribution B/W
    LDPB_PLT4PXEW_835-Spectral power distribution B/W
    LDPO_PLT4PXEW_835-Spectral power distribution Colour
    LDPO_PLT4PXEW_835-Spectral power distribution Colour
    Downloads
    Leaflets
    Visuals
