12.5T8/COR/48-835/FF17/G/DIM 25/1

Specifications Show all

Operating and Electrical

Line Frequency	50 to 60 Hz
Warm-up time to 60% light	0.5 s
Voltage (Nom)	120-277 V
Starting Time (Nom)	0.5 s
Power Factor (Fraction)	0.9
Wattage Equivalent	32 W
Input Frequency	50 to 60 Hz
Power Consumption	12.5 W	13 W

Approval and Application

Approval Marks	RoHS compliance	UL certificate	DLC compliance
Energy Saving Product	Yes

Product Data

Order product name	12.5T8/COR/48-835/FF17/G/DIM 25/1
EAN/UPC - Case	50046677560190
Net weight	0.220 kg
Numerator - Packs per outer box	25
Full product name	12.5T8/COR/48-835/FF17/G/DIM 25/1
Material number (12NC)	929002402204
Order code	560193
Numerator - Quantity Per Pack	1

Controls and Dimming

Dimmable

Only with specific dimmers

Mechanical and Housing

Product Length	47-1/4 inch
Bulb Finish	Frosted
Bulb Shape	Tube, double-ended
Bulb Material	Glass

General Information

Switching Cycle	50,000
Cap-Base	G13  [Medium Bi-Pin Fluorescent]
Lighting Technology	LED
EU RoHS compliant	Yes
Nominal lifetime	50,000 hour(s)
Brand	Philips

Temperature

T-Case Maximum (Nom)	140 °F
Ambient temperature range	-20 °C to 45 °C

Light Technical

Correlated Color Temperature (Nom)	3500 K
Luminous Efficacy (rated) (Nom)	130 lm/W
Luminous Flux	1,700 lumen
LLMF At End Of Nominal Lifetime (Nom)	70 %
Color Designation	White (WH)
Color Consistency	<6
Beam Angle (Nom)	220 degree(s)
Color rendering index (CRI)	82
Color Code	835  [CCT of 3500K]
