    • Everything you value in a Halogen PAR38 with the benefits of LED. Accent your merchandise or space without distraction.

      17PAR38/EXPERTCOLOR RETAIL/S8/930/DIM
      LED
      17PAR38/EXPERTCOLOR RETAIL/S8/930/DIM
      LED PAR38

      17PAR38/EXPERTCOLOR RETAIL/S8/930/DIM

      Order code: 470996

      Downloads

      Spec Sheet
      Size:468.5 kB

      See all downloads

    Specifications Show all

    General information
    Base
    E26  [ Single Contact Medium Screw]
    EU RoHS compliant
    Yes
    Nominal Lifetime (Nom)
    25000 h
    Switching Cycle
    50000
    Tier
    MasterClass
    Light technical
    Color Code
    930  [ CCT of 3000K]
    Beam Angle (Nom)
    8 °
    Initial lumen (Nom)
    1200 lm
    Luminous Intensity (Nom)
    22000 cd
    Color Designation
    White (WH)
    Correlated Color Temperature (Nom)
    3000 K
    Luminous Efficacy (rated) (Nom)
    70 lm/W
    Color Consistency
    <6
    Color Rendering Index (Nom)
    90
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Operating and electrical
    Input Frequency
    60 Hz
    Power (Rated) (Nom)
    17 W
    Lamp Current (Nom)
    170 mA
    Wattage Equivalent
    100 W
    Starting Time (Nom)
    0.5 s
    Warm Up Time to 60% Light (Nom)
    0.5 s
    Power Factor (Nom)
    0.9
    Voltage (Nom)
    120 V
    Temperature
    T-Case Maximum (Nom)
    194 °F
    Controls and dimming
    Dimmable
    Yes
    Mechanical and housing
    Bulb Finish
    Clear
    Bulb Material
    Plastic
    Bulb Shape
    PAR38  [ PAR 4.75 inch/121mm]
    Approval and application
    Suitable For Accent Lighting
    Yes
    Energy Consumption kWh/1000 h
    - kWh
    Energy Certifications
    Energy Star
    Product data
    Order product name
    17PAR38/EXPERTCOLOR RETAIL/S8/930/DIM
    EAN/UPC - Product
    046677470999
    Order code
    470996
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    6
    Material Nr. (12NC)
    929001285204
    Net Weight (Piece)
    0.937 lb

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
    PAR30L
    PAR30L
    E26
    E26
    Performance Diagrams
    ExpertColor PAR38 30S 30L Dim  120V Lumen Maintenance Diagram
    ExpertColor PAR38 30S 30L Dim 120V Lumen Maintenance Diagram
    ExpertColor PAR38 30S 30L Dim  120V Life Expectancy Diagram
    ExpertColor PAR38 30S 30L Dim 120V Life Expectancy Diagram
    Photometrics
    PAR38 120V 17-90W 1200lm 8D 3000K E26 D
    PAR38 120V 17-90W 1200lm 8D 3000K E26 D
    PAR38 120V 17-90W 1200lm 8D 3000K E26 D
    PAR38 120V 17-90W 1200lm 8D 3000K E26 D
    PAR38 120V 17-90W 1200lm 8D 3000K E26 D
    PAR38 120V 17-90W 1200lm 8D 3000K E26 D
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES PAR38 120V 17-90W 1200lm 8D 3000K E26 D IES 1.6 kB
