9.4PAR30L/COR/930/F25/DIM/120V T20 6/1FB

Specifications Show all

General information

Base	E26  [ Single Contact Medium Screw]
EU RoHS compliant	Yes
Nominal Lifetime (Nom)	25000 h
Switching Cycle	50000

Light technical

Color Code	930  [ CCT of 3000K]
Beam Angle (Nom)	25 °
Initial lumen (Nom)	850 lm
Luminous Intensity (Nom)	2910 cd
Color Designation	White (WH)
Correlated Color Temperature (Nom)	3000 K
Luminous Efficacy (rated) (Nom)	90.00 lm/W
Color Consistency	<4
Color Rendering Index (Nom)	90
LLMF At End Of Nominal Lifetime (Nom)	70 %

Operating and electrical

Input Frequency	50 to 60 Hz
Power (Rated) (Nom)	9.4 W
Lamp Current (Nom)	90 mA
Wattage Equivalent	75 W
Starting Time (Nom)	0.5 s
Warm Up Time to 60% Light (Nom)	0.5 s
Power Factor (Nom)	0.9
Voltage (Nom)	120 V

Temperature

T-Case Maximum (Nom)

176 °F

Controls and dimming

Dimmable

Yes

Mechanical and housing

Bulb Finish	Clear
Bulb Material	Plastic
Bulb Shape	PAR30L  [ PAR 3.75 inch/95mm Long]

Approval and application

Suitable For Accent Lighting	Yes
Energy Consumption kWh/1000 h	- kWh
Energy Certifications	Energy Star

Product data

Order product name	9.4PAR30L/COR/930/F25/DIM/120V T20 6/1FB
EAN/UPC - Product	046677546960
Order code	546969
Numerator - Quantity Per Pack	1
Numerator - Packs per outer box	6
Material Nr. (12NC)	929002045404
Net Weight (Piece)	0.628 lb
