    • The optimal LED accent light with a seamless look.

      8.5PAR20/PER/930/F40/DIM/EC/120V 6/1FB
      LED
      8.5PAR20/PER/930/F40/DIM/EC/120V 6/1FB
      LED PAR20

      8.5PAR20/PER/930/F40/DIM/EC/120V 6/1FB

      Order code: 535300

      Downloads

      Spec Sheet
      Size:599.7 kB

      See all downloads

    Specifications Show all

    General information
    Base
    E26  [ Single Contact Medium Screw]
    EU RoHS compliant
    Yes
    Nominal Lifetime (Nom)
    25000 h
    Switching Cycle
    50000
    Tier
    MasterClass
    Light technical
    Color Code
    930  [ CCT of 3000K]
    Beam Angle (Nom)
    40 °
    Initial lumen (Nom)
    610 lm
    Luminous Intensity (Nom)
    1100 cd
    Color Designation
    White (WH)
    Correlated Color Temperature (Nom)
    3000 K
    Luminous Efficacy (rated) (Nom)
    71.00 lm/W
    Color Consistency
    <4
    Color Rendering Index (Nom)
    95
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Operating and electrical
    Input Frequency
    50 to 60 Hz
    Power (Rated) (Nom)
    8.5 W
    Lamp Current (Nom)
    86 mA
    Wattage Equivalent
    50 W
    Starting Time (Nom)
    0.5 s
    Warm Up Time to 60% Light (Nom)
    0.5 s
    Power Factor (Nom)
    0.8
    Voltage (Nom)
    120 V
    Temperature
    T-Case Maximum (Nom)
    186.8 °F
    Controls and dimming
    Dimmable
    Yes
    Mechanical and housing
    Bulb Finish
    Clear
    Bulb Material
    Plastic
    Bulb Shape
    PAR20  [ PAR 2.5 inch]
    Approval and application
    Suitable For Accent Lighting
    Yes
    Energy Consumption kWh/1000 h
    - kWh
    Energy Certifications
    Energy Star
    Product data
    Order product name
    8.5PAR20/PER/930/F40/DIM/EC/120V 6/1FB
    EAN/UPC - Product
    046677535308
    Order code
    535300
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    6
    Material Nr. (12NC)
    929001922204
    Net Weight (Piece)
    0.298 lb

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Single Contact Medium Screw PAR 2.5 inch Clear
    Single Contact Medium Screw PAR 2.5 inch Clear
    E26
    E26
    Performance Diagrams
    LEDSpot PAR20 E26
    LEDSpot PAR20 E26
    LEDSpot PAR20 E26
    LEDSpot PAR20 E26
    Photometrics
    LEDSpot PAR20 E26 3000K 40D
    LEDSpot PAR20 E26 3000K 40D
    LEDSpot PAR20 E26 3000K
    LEDSpot PAR20 E26 3000K
    LEDSpot PAR20 E26 3000K 40D
    LEDSpot PAR20 E26 3000K 40D
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES LEDSpot PAR20 E26 3000K 40D 560lm IES 10.6 kB
