      45HB/LED/850/ND FB 6/1
      LED
      45HB/LED/850/ND FB 6/1
      LED Highbay

      45HB/LED/850/ND FB 6/1

      Order code: 541978

      Downloads

      Spec Sheet
      Size:704.3 kB

      See all downloads

    Specifications Show all

    General information
    Base
    E26  [ Single Contact Medium Screw]
    EU RoHS compliant
    Yes
    Nominal Lifetime (Nom)
    25000 h
    Switching Cycle
    50000
    Tier
    CorePro
    Light technical
    Color Code
    850  [ CCT of 5000K]
    Beam Angle (Nom)
    200 °
    Initial lumen (Nom)
    4800 lm
    Color Designation
    Daylight
    Correlated Color Temperature (Nom)
    5000 K
    Luminous Efficacy (rated) (Nom)
    106.00 lm/W
    Color Consistency
    <6
    Color Rendering Index (Nom)
    80
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Operating and electrical
    Input Frequency
    50 to 60 Hz
    Power (Rated) (Nom)
    45 W
    Lamp Current (Nom)
    400 mA
    Wattage Equivalent
    100 W
    Starting Time (Nom)
    0.5 s
    Warm Up Time to 60% Light (Nom)
    0.5 s
    UL Type
    Type B - bypass the ballast
    Power Factor (Nom)
    0.92
    Voltage (Nom)
    120 V
    Temperature
    T-Ambient (Max)
    113 °F
    T-Ambient (Min)
    -4 °F
    T-Case Maximum (Nom)
    148.1 °F
    Controls and dimming
    Dimmable
    No
    Mechanical and housing
    Bulb Finish
    Frosted
    Bulb Material
    Plastic
    Bulb Shape
    T-shape
    Approval and application
    Energy Consumption kWh/1000 h
    - kWh
    Application conditions
    Ambient temperature range
    -20 °C to 45 °C
    Product data
    Order product name
    45HB/LED/850/ND FB 6/1
    EAN/UPC - Product
    046677541972
    Order code
    541978
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    6
    Material Nr. (12NC)
    929001990204
    Net Weight (Piece)
    0.765 lb

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Single Contact Medium Screw T-shape Frosted
    Single Contact Medium Screw T-shape Frosted
    E26
    E26
    Performance Diagrams
    LEDTrueForce E26 120-240V
    LEDTrueForce E26 120-240V
    LEDTrueForce E26 120-240V
    LEDTrueForce E26 120-240V
    Photometrics
    LEDTrueForce E26 120-240V 45HB 850 42W
    LEDTrueForce E26 120-240V 45HB 850 42W
    LEDTrueForce E26 120-240V 45HB 850 42W
    LEDTrueForce E26 120-240V 45HB 850 42W
    LEDTrueForce E26 120-240V 45HB
    LEDTrueForce E26 120-240V 45HB
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES LEDTrueForce E26 120-240V 45HB 850 42W IES 942 B
