      80CC/LED/840/LS EX39 G2 BB 3/1
      LED
      80CC/LED/840/LS EX39 G2 BB 3/1
      LED Corn Cobs

      80CC/LED/840/LS EX39 G2 BB 3/1

      Order code: 564054

      Downloads

      Spec Sheet
      Size:756.9 kB

      See all downloads

    Specifications Show all

    General information
    Base
    EX39  [ Exclusionary Mogul Screw]
    Nominal Lifetime (Nom)
    50000 h
    Switching Cycle
    50000
    Tier
    MASTER
    Light technical
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Operating and electrical
    Input Frequency
    50 to 60 Hz
    Power (Rated) (Nom)
    80 W
    Wattage Equivalent
    250(175-250) W
    Power Factor (Nom)
    0.9
    Voltage (Nom)
    120-277 V
    Temperature
    T-Ambient (Max)
    113 °F
    T-Ambient (Min)
    -4 °F
    T-Case Maximum (Nom)
    99 °F
    Controls and dimming
    Dimmable
    Preset Dimming
    Mechanical and housing
    Bulb Finish
    Clear
    Bulb Material
    Plastic
    Bulb Shape
    Corncob
    Application conditions
    Ambient temperature range
    -20 °C to 45 °C
    Product data
    Order product name
    80CC/LED/840/LS EX39 G2 BB 3/1
    EAN/UPC - Product
    046677564056
    Order code
    564054
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    3
    Material Nr. (12NC)
    929002996104
    Net Weight (Piece)
    1.554 lb

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Exclusionary Mogul Screw Corncob Clear
    Exclusionary Mogul Screw Corncob Clear
    EX39
    EX39
    Performance Diagrams
    Lumen Maintenance Diagram
    Lumen Maintenance Diagram
    Photometrics
    LEDTForce LS 80W Corncob EX39 840-GUL
    LEDTForce LS 80W Corncob EX39 840-GUL
    LEDTForce LS 80W Corncob EX39 840-POC
    LEDTForce LS 80W Corncob EX39 840-POC
    LEDTForce LS 80W Corncob EX39-LDD
    LEDTForce LS 80W Corncob EX39-LDD
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES LEDTForce LS 80W Corncob EX39 840-IES IES 11.5 kB
