      3.6T3/PER/830/ND/G9/120V 6/3BC
      LED
      3.6T3/PER/830/ND/G9/120V 6/3BC

      3.6T3/PER/830/ND/G9/120V 6/3BC

      Order code: 534263

      Downloads

      Spec Sheet
      Size:716.7 kB

      See all downloads

    Specifications Show all

    General Information
    Base
    G9  [ G9]
    EU RoHS compliant
    Yes
    Nominal Lifetime (Nom)
    15000 h
    Switching Cycle
    50000X
    Technical Type
    3.6-40W
    Light Technical
    Color Code
    830  [ CCT of 3000K]
    Initial lumen (Nom)
    370 lm
    Color Designation
    White (WH)
    Correlated Color Temperature (Nom)
    3000 K
    Luminous Efficacy (rated) (Nom)
    102.00 lm/W
    Color Consistency
    <6
    Color Rendering Index (Nom)
    80
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Operating and Electrical
    Input Frequency
    60 Hz
    Power (Rated) (Nom)
    3.6 W
    Lamp Current (Nom)
    60 mA
    Wattage Equivalent
    40 W
    Starting Time (Nom)
    0.5 s
    Warm Up Time to 60% Light (Nom)
    0.5 s
    Power Factor (Nom)
    0.5
    Voltage (Nom)
    120 V
    Temperature
    T-Case Maximum (Nom)
    78 °C
    Controls and Dimming
    Dimmable
    No
    Approval and Application
    Energy Efficiency Label (EEL)
    Not applicable
    Suitable For Accent Lighting
    No
    Product Data
    Order product name
    3.6T3/PER/830/ND/G9/120V 6/3BC
    EAN/UPC - Product
    50046677534269
    Order code
    534263
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    6
    Material Nr. (12NC)
    929001840835
    Net Weight (Piece)
    0.007 kg

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     G9 Capsule
    G9 Capsule
    G9
    G9
    Performance Diagrams
    15K LMP
    15K LMP
    15K LED
    15K LED
    Photometrics
    LEDcapsule 3,6W G9 830
    LEDcapsule 3,6W G9 830
    LEDcapsule 3,6W G9 830
    LEDcapsule 3,6W G9 830
    LEDcapsule 3,6W G9
    LEDcapsule 3,6W G9
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES LEDcapsule 3,6W G9 830 IES 41.4 kB
