    • Exceptional LED alternatives for unique applications

      3T3/PER/830/ND/G9/120V 6/1BC
      LED
      3T3/PER/830/ND/G9/120V 6/1BC
      LED Specialty Lamps

      3T3/PER/830/ND/G9/120V 6/1BC

      Order code: 465138

      Downloads

      Spec Sheet
      Size:417.0 kB

      See all downloads

    Specifications Show all

    General information
    Base
    G9  [ G9]
    EU RoHS compliant
    Yes
    Nominal Lifetime (Nom)
    15000 h
    Switching Cycle
    50000
    Light technical
    Color Code
    830  [ CCT of 3000K]
    Initial lumen (Nom)
    250 lm
    Color Designation
    White (WH)
    Correlated Color Temperature (Nom)
    3000 K
    Luminous Efficacy (rated) (Nom)
    83.00 lm/W
    Color Consistency
    <6
    Color Rendering Index (Nom)
    80
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Operating and electrical
    Input Frequency
    50 to 60 Hz
    Power (Rated) (Nom)
    3 W
    Lamp Current (Nom)
    40 mA
    Wattage Equivalent
    25 W
    Starting Time (Nom)
    0.5 s
    Warm Up Time to 60% Light (Nom)
    0.5 s
    Power Factor (Nom)
    0.5
    Voltage (Nom)
    120 V
    Temperature
    T-Case Maximum (Nom)
    149 °F
    Controls and dimming
    Dimmable
    No
    Mechanical and housing
    Bulb Finish
    Clear
    Bulb Material
    Plastic
    Bulb Shape
    Capsule
    Approval and application
    Suitable For Accent Lighting
    Yes
    Energy Certifications
    No
    Product data
    Order product name
    3T3/PER/830/ND/G9/120V 6/1BC
    EAN/UPC - Product
    046677465131
    Order code
    465138
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    6
    Material Nr. (12NC)
    929001266825
    Net Weight (Piece)
    0.013 lb

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     G9 Capsule Clear
    G9 Capsule Clear
    G9
    G9
    Performance Diagrams
    Lumen Maintenance Diagram
    Lumen Maintenance Diagram
    Life Expectancy Diagram
    Life Expectancy Diagram
    Photometrics
    LEDcapsule 3W G9 830
    LEDcapsule 3W G9 830
    LEDcapsule 3W G9 830
    LEDcapsule 3W G9 830
    LEDcapsule 3W G9
    LEDcapsule 3W G9
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES LEDcapsule 3W G9 830 IES 3.6 kB
