      16UFO/PER/830/FR/P/E26/ND 4/1PF
      LED
      16UFO/PER/830/FR/P/E26/ND 4/1PF
      LED Designer Deco

      16UFO/PER/830/FR/P/E26/ND 4/1PF

      Downloads

      Spec Sheet
      Size:762.9 kB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Lamp Current (Nom)
    230 mA
    Warm-up time to 60% light
    0.5 s
    Voltage (Nom)
    110-240 V
    Power Factor (Fraction)
    0.5
    Wattage Equivalent
    75 W
    Starting Time (Nom)
    0.5 s
    Line Frequency
    50 to 60 Hz
    Power Consumption
    16 W
    Input Frequency
    50 to 60 Hz
    Approval and Application
    Energy Consumption kWh/1000 h
    - kWh
    EU RoHS compliant
    Yes
    Product Data
    Full product name
    16UFO/PER/830/FR/P/E26/ND 4/1PF
    EAN/UPC - Case
    50046677561654
    Order code
    561654
    Numerator - Packs per outer box
    4
    Material number (12NC)
    929002010503
    Numerator - Quantity Per Pack
    1
    Order product name
    16UFO/PER/830/FR/P/E26/ND 4/1PF
    Controls and Dimming
    Dimmable
    No
    General Information
    Cap-Base
    E26  [Single Contact Medium Screw]
    Switching Cycle
    50,000
    Lighting Technology
    LED
    Nominal lifetime
    15,000 hour(s)
    Mechanical and Housing
    Bulb Shape
    Others
    Bulb Finish
    Frosted
    Bulb Material
    Plastic
    Temperature
    T-Case Maximum (Nom)
    167 °F
    Light Technical
    Luminous Flux
    1,150 lumen
    Luminous Efficacy (rated) (Nom)
    71.00 lm/W
    Color rendering index (CRI)
    80
    Correlated Color Temperature (Nom)
    3000 K
    Beam Angle (Nom)
    120 degree(s)
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Color Designation
    White (WH)
    Color Consistency
    <6
    Color Code
    830  [CCT of 3000K]

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Single Contact Medium Screw Others Frosted
    Single Contact Medium Screw Others Frosted
    E26
    E26
    Performance Diagrams
    Lumen Maintenance Diagram - 16UFO/PER/830/FR/P/E26/ND 4/1PF
    Lumen Maintenance Diagram - 16UFO/PER/830/FR/P/E26/ND 4/1PF
    Life Expectancy Diagram - 16UFO/PER/830/FR/P/E26/ND 4/1PF
    Life Expectancy Diagram - 16UFO/PER/830/FR/P/E26/ND 4/1PF
    Photometrics
    General uniform lighting
    General uniform lighting
    Spectral Power Distribution Colour
    Spectral Power Distribution Colour
    Light Distribution Diagram - 16UFO/PER/830/FR/P/E26/ND 4/1PF
    Light Distribution Diagram - 16UFO/PER/830/FR/P/E26/ND 4/1PF
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES IES File - 16UFO/PER/830/FR/P/E26/ND 4/1PF IES 5.5 kB
