3.3A15/VIN/820/E26/CL/GL/DIM 4/FBHT20

Specifications Show all

Operating and Electrical

Lamp Current (Nom)	40 mA
Warm-up time to 60% light	0.5 s
Voltage (Nom)	120 V
Power Factor (Fraction)	0.7
Wattage Equivalent	25 W
Line Frequency	60 Hz
Power Consumption	3.3 W
Starting Time (Nom)	0.5 s
Input Frequency	60 Hz

Approval and Application

Energy Consumption kWh/1000 h	- kWh
Energy Certifications	No
EU RoHS compliant	Yes

Product Data

Full product name	3.3A15/VIN/820/E26/CL/GL/DIM 4/FBHT20
EAN/UPC - Case	50046677556551
Order code	556555
Material number (12NC)	929002260203
Numerator - Quantity Per Pack	1
Numerator - Packs per outer box	4
Order product name	3.3A15/VIN/820/E26/CL/GL/DIM 4/FBHT20

Controls and Dimming

Dimmable

Yes

General Information

Cap-Base	E26  [Single Contact Medium Screw]
Switching Cycle	20,000
Rated Lifetime (Hours)	15,000 hour(s)
Nominal lifetime	15,000 hour(s)
Lighting Technology	LED

Mechanical and Housing

Bulb Shape	A15  [A 15mm]
Bulb Material	Glass
Bulb Finish	Transparent amber

Temperature

T-Case Maximum (Nom)

122 °F

Light Technical

Luminous Flux	200 lumen
Luminous Efficacy (rated) (Nom)	60.00 lm/W
Color rendering index (CRI)	80
Correlated Color Temperature (Nom)	2000 K
Color Designation	Flame
Color Consistency	<6
Color Code	820  [CCT of 2000K]
LLMF At End Of Nominal Lifetime (Nom)	70 %
