MASTER GreenPower CG T 600W Mogul 1SL/12

Specifications Show all

General information

Base	E39  [ Single Contact Mogul Screw]
Operating Position	Universal  [ Universal]
Life to 5% Failures (Nom)	9500 h
Life To 10% Failures (Nom)	14000 h
Life to 20% Failures (Nom)	20000 h
Life to 50% Failures (Nom)	32000 h
System Description	External Ignitor (E)

Light technical

Color Code	220  [ CCT of 2000K]
Luminous Flux (Rated) (Nom)	88000 lm
Photosynthetic Photon Flux (PPF)	1100 µmol/s
PPF Maintenance 2000 h	97 %
PPF Maintenance 5000 h	93 %
PPF Maintenance 10000 h	91 %
PPF Maintenance 12000 h	89 %
Design Mean Lumens	80960 lm
Chromaticity Coordinate X (Nom)	533
Chromaticity Coordinate Y (Nom)	432
Correlated Color Temperature (Nom)	2000 K
Luminous Efficacy (rated) (Nom)	142.4 lm/W
Color Rendering Index (Max)	-
Color Rendering Index (Nom)	26

Operating and electrical

Lamp supply voltage	230 V  [ 230]
Power (Rated) (Min)	618.0 W
Power (Rated) (Nom)	618.0 W
Lamp Current (EM) (Nom)	6.3 A
Ignition Supply Voltage (Max)	220 V
Ignition Peak Voltage (Max)	3500 V
Re-Ignition Time (Min) (Max)	1 min
Ignition Time (Max)	10 s
Voltage (Max)	145 V
Voltage (Min)	115 V
Voltage (Nom)	130 V

Controls and dimming

Dimmable	Yes
Run-Up Time 90% (Max)	5 min

Mechanical and housing

Bulb Finish	Clear
Cap-Base Information	41
Bulb Shape	T14 /2  [ Diameter: 1.8125 inch]

Approval and application

Mercury (Hg) Content (Nom)	30.0 mg
Energy Consumption kWh/1000 h	680 kWh

Luminaire design requirements

Bulb Temperature (Max)	752 °F
Cap-Base Temperature (Max)	482 °F
Cap-Base Temperature (Max)-DUP(do not use)	482 °F

Product data

Order product name	MASTER GreenPower CG T 600W Mogul 1SL/12
EAN/UPC - Product	046677404888
Order code	404889
Numerator - Quantity Per Pack	1
Numerator - Packs per outer box	12
Material Nr. (12NC)	928197709207
Net Weight (Piece)	0.401 lb
ILCOS Code	ST-600-H/S-E39
