• Halogen non-reflector lamps – high-quality light and easy to use

    12345SL 20W G4 12V 1CT/24

    12345SL 20W G4 12V 1CT/24

    Downloads

    Spec Sheet
    Size:141.5 kB
    Spec Sheet
    Size:388.3 kB

    See all downloads

Videos

[trigger to render Video Gallery]

Images

Specifications Show all

General Information
Cap-Base
G4  [ G4]
Philips Code
12345SL
Operating Position
Universal  [ Universal]
Main Application
Projection
Life To 50% Failures (Nom)
100 h
Light Technical
Luminous Flux (Rated) (Nom)
640 lm
Correlated Color Temperature (Nom)
3100 K
Color Rendering Index (Nom)
100
Operating and Electrical
Power (Rated) (Nom)
20 W
Voltage (Nom)
12 V
Mechanical and Housing
Bulb Material
Quartz-UV Open
Filament Dimensions WxH
-
Luminaire Design Requirements
Bulb Temperature (Max)
900 °C
Pinch Temperature (Max)
400 °C
Product Data
Order product name
12345SL 20W G4 12V 1CT/24
EAN/UPC - Product
8718696690239
Order code
324046
Numerator - Quantity Per Pack
1
Numerator - Packs per outer box
24
Material Nr. (12NC)
924068417104
Net Weight (Piece)
1.000 g
Installation Diagrams
G4
G4
