• MSR Gold™ SA Double Ended – for extended performance

    MSR Gold™ 1510 SA/1 DE 1CT/4

    MSR Gold™ 1510 SA/1 DE 1CT/4

    Full Product Code: 871869653613100

    Order code: 325399

    Downloads

    Spec Sheet
    Size:318.4 kB
    Spec Sheet
    Size:318.4 kB

    See all downloads

Videos

[trigger to render Video Gallery]

Images

Specifications Show all

General Information
Cap-Base
SFC10-4  [ SFC10-4]
Operating Position
Universal  [ Universal]
Main Application
Entertainment
Life To 50% Failures (Nom)
750 h
System Description
SA/DE
Light Technical
Color Code
-  [ Not Specified]
Initial lumen (Nom)
141000 lm
Chromaticity Coordinate X (Nom)
330
Chromaticity Coordinate Y (Nom)
338
Correlated Color Temperature (Nom)
5600 K
Luminous Efficacy (rated) (Nom)
94 lm/W
Color Rendering Index (Nom)
90
Operating and Electrical
Power (Rated) (Nom)
1510 W
Lamp Current (Nom)
13.4 A
Ignition Supply Voltage (Min)
198 V
Controls and Dimming
Dimmable
Yes
Mechanical and Housing
Cap-Base Information
SFC10-4
Luminaire Design Requirements
Bulb Temperature (Max)
950 °C
Pinch Temperature (Max)
450 °C
Product Data
Full product code
871869653613100
Order product name
MSR Gold™ 1510 SA/1 DE 1CT/4
EAN/UPC - Product
8718696536131
Order code
325399
Numerator - Quantity Per Pack
1
Numerator - Packs per outer box
4
Material Nr. (12NC)
928410005115
Net Weight (Piece)
34.000 g
Installation Diagrams
Photometrics
MSR Gold™ 1200 SA/DE, MSR Gold™ 1510 SA/DE
MSR Gold™ 1200 SA/DE, MSR Gold™ 1510 SA/DE
MSR Gold™ 1200 SA/DE, MSR Gold™ 1510 SA/DE
MSR Gold™ 1200 SA/DE, MSR Gold™ 1510 SA/DE
