• High performance, low total cost of ownership

    MS250/BU/PS 12PK

    MS250/BU/PS 12PK

    Order code: 276618

    Downloads

    Spec Sheet
    Size:292.6 kB
    Spec Sheet
    Size:292.6 kB

    See all downloads

Videos

[trigger to render Video Gallery]

Images

Specifications Show all

General Information
Cap-Base
E39  [ Single Contact Mogul Screw]
Operating Position
Base Up +/- 15 D  [ Base Up +/- 15 D]
Main Application
General Lighting (G)
Life To 50% Failures (Nom)
15000 h
ANSI Code HID
M153/M138/E
System Description
Pulse Start
Light Technical
Color Code
645  [ CCT of 4500K]
Luminous Flux (Rated) (Min)
21375 lm
Luminous Flux (Rated) (Nom)
23750 lm
Color Designation
Cool White (CW)
Design Mean Lumens
16625 lm
Chromaticity Coordinate X (Nom)
374
Chromaticity Coordinate Y (Nom)
392
Correlated Color Temperature (Nom)
4300 K
Luminous Efficacy (rated) (Min)
85.5 lm/W
Luminous Efficacy (rated) (Nom)
95 lm/W
Color Rendering Index (Nom)
65
Operating and Electrical
Lamp Current (Nom)
2 A
Ignition Supply Voltage (Min)
254 V
Re-Ignition Time (Min) (Max)
4 min
Ignition Time (Max)
120 s
Voltage (Max)
147 V
Voltage (Min)
119 V
Voltage (Nom)
133 V
Mechanical and Housing
Bulb Finish
Clear (CL)
Cap-Base Information
Nic/Brass
Bulb Material
Hard Glass
Approval and Application
Mercury (Hg) Content (Max)
32.6 mg
UV
Pet (Niosh) (Nom)
80.8 h/500lx
Damage Factor D/fc (Nom)
0.49
Luminaire Design Requirements
Bulb Temperature (Max)
400 °C
Cap-Base Temperature (Max)
210 °C
Product Data
Order product name
MS250/BU/PS 12PK
EAN/UPC - Product
046677276614
Order code
276618
Numerator - Quantity Per Pack
1
Numerator - Packs per outer box
12
Material Nr. (12NC)
928601152203
Net Weight (Piece)
0.001 kg

Eco passport - Our environmental product specifications overview

Philips cares about the environment and society at large, and strongly supports eco-design of products.

Installation Diagrams
E39, ED-28
E39, ED-28
E39
E39
